Industrial 4G PoE Router

Model: R2120



Industrial 4G PoE Router Product Overview

A specialized industrial router designed for smart security and IoT applications, delivering stable cellular connectivity and advanced Power over Ethernet (PoE) capabilities.

● Advanced Power over Ethernet (PoE): Features 4 x PoE-PSE Ethernet ports (802.3af/at) to power and connect devices like IP cameras and access points through a single cable, simplifying installation. Includes remote PoE device management via RCMS to schedule reboots and power cycles.

● Stable & Redundant Connectivity:Combines 4G/3G/2G cellular, Wi-Fi, and Ethernet with dual-SIM automatic failover for resilient, always-on communications.

● Enterprise-Grade Security: Runs on the hardened RobustOS. Secures your network with a powerful stateful firewall and a comprehensive suite of VPNs, including IPsec, OpenVPN, and DMVPN.

● Simplified Cloud Management:Integrates fully with the RCMS cloud platform for centralized monitoring of your entire fleet, Over-the-Air (OTA) updates, and secure remote management of both the router and connected PoE devices.

Router Hardware Specifications

System

● CPU: MT7621, 880 MHz

● RAM: 512 MB

● Storage: 32 MB

● Indicators: LED for RUN, RSSI, MDM, USR

Network Connectivity

● Cellular (4G LTE):

● Frequencies: EMEA+SEA / ANZ Coverage (See Ordering Information for specific bands)

● SIM: 2 x Mini SIM (2FF), Dual SIM Failover

● Antennas: 2 x SMA Connectors

● Wi-Fi:

● Standard: 802.11 a/b/g/n/ac, Dual-Band (2.4 GHz & 5 GHz)

● Modes: Access Point (AP), Client

● Antennas: 2 x RP-SMA Connectors

Interfaces

● Ethernet: 5 x 10/100/1000 Mbps, RJ45 (1x WAN + 4x LAN, or 5x LAN)

● PoE Output: 4 x PoE-PSE Ports (ETH1-ETH4), 802.3af/at compliant, up to 30W per port

● Serial: 1 x RS-485

● Digital I/O: 2 x DI, 2 x DO (Wet contact)

Power & Physical

● Input Voltage: 44 to 57 VDC (2-pin terminal block with lock)

● Power Consumption: ~4.5W (Idle @ 48V), ~12W (Max @ 48V) - excluding PoE consumption

● Housing: Aluminum

● Protection: IP30

● Dimensions: 49 x 105 x 143 mm

● Weight: 539 g

● Installation: DIN-Rail, Wall Mount, Desktop

Environmental

● Operating Temperature: -20°C to +70°C

● Storage Temperature: -40°C to +85°C

● Relative Humidity: 5% to 95% (non-condensing)

Certifications

● Global Regulatory: CE, UKCA, CB, RCM

● Environmental Standards: RoHS2.0, WEEE

Software

Operating System

● OS: RobustOS (Linux-based, optimized for Robustel industrial routers)

Key Supported Software & Protocols

● Industrial Protocols: Modbus RTU to TCP Gateway

● Supported Applications/Features: L2TP, PPTP, DMVPN, VRRP, QoS, SNMP, Dynamic Routing, Captive Portal, Edge2Cloud

Networking

● Network Protocols: TCP, UDP, IPv4, PPP, PPPoE, DHCP, ICMP, NAT, HTTP(S), DNS, NTP, SMTP, Telnet, VLAN, SSH2, DDNS

● Serial Port Protocols: Transparent TCP Client/Server, UDP, Modbus RTU to TCP

Security

● VPN: IPsec, OpenVPN, Wireguard, GRE, L2TP, PPTP, DMVPN

● Firewall: Stateful firewall with DMZ, anti-DoS, Filtering (IP/Domain/MAC), Port Mapping, Access Control

SDK & Customization

● SDK Languages: C, C++

● Available Resources: 5 MB Flash, 256 MB RAM for user applications

Management

● Configuration Interfaces: Web GUI, Command Line Interface (CLI), SMS

● Remote Management Platform: Robustel Cloud Manager Service (RCMS)

● RCMS Features:

● Centralized Monitoring & Control

● Fleet-wide Over-the-Air (OTA) updates

● Secure Remote Access to devices and their PoE status

● Experience robust, cloud-native device management by registering at:

Robustel Cloud Manager Service

Industrial IoT solutions Applications

● Smart Security

● CCTV

● IP Camera Connectivity

● Industrial Automation

● Smart City



Why Robustel?

● Industrial grade fanless design

● Up to 10 years hardware lifetime

● Up to 10 years long term support for Linux

● Up to 5 years hardware warranty

● Global certifications

● Robust connectivity



Ordering Information

● Order code: A015000004

● Package contains: 1 x R2120, 1 x DIN-Rail, 2 x cellular antennas, 2 x Wi-Fi antennas, 1 x global power adapter
