Case Study: Using a 4G LTE Edge Router for Remote Pump Station Monitoring

For water utilities, a "silent failure" at a remote pump station is a costly and hazardous event. This case study shows how a municipal utility deployed a Robustel 4g lte edge router to solve its biggest remote pump monitoring challenge. By using this rugged cellular edge router to connect directly to the pump's PLC and sensors, they gained 100% real-time visibility. This edge router solution, managed by RCMS, eliminated 90% of costly "truck rolls" and prevented several catastrophic overflow events, delivering a complete ROI in under six months.

If you work in water or wastewater management, you know the sound that keeps you up at night: silence. The silence of a remote lift station pump that should be running. The silence before your phone rings at 3 AM with a citizen reporting a sewage overflow.

This is the central crisis of smart water management. Your most critical assets are scattered across miles of remote, hard-to-reach locations. They are "offline" by default. You're forced to operate in the dark, relying on two terrible strategies:

1. Expensive Manual Checks: Sending a technician in a truck on a 4-hour loop just to "eyeball" 20 different pump stations and see if a red light is on.
2. Reactive Failure Response: Waiting for the catastrophic failure to happen (a flood, an overflow, a service outage) and then scrambling to fix it.

This isn't just inefficient; it's expensive and dangerous. We worked with a municipal utility that was trapped in this cycle. This is the story of how a single, rugged 4g lte edge router transformed their entire operation.

A regional water utility was responsible for 120 remote pump and lift stations. Their TCO for "Operations & Maintenance" was skyrocketing.

• The Cost: They were spending over $250,000 a year just on the fuel and labor for "preventive" manual inspections, which often found nothing.
• The Risk: In the last year, they had three major overflow events caused by pump clogs and controller failures. The fines and clean-up costs exceeded $750,000, not to mention the PR nightmare.
• The Blocker: These sites had no internet. They were concrete bunkers in fields or by the roadside. Running wired internet was impossible. They needed a reliable edge router solution for remote monitoring.

The utility launched a new smart water management initiative. The goal: get 100% visibility on all 120 stations. The chosen solution: a Robustel R1520 industrial edge router installed in each pump station's control cabinet.

This 4g lte edge router was the perfect tool. It wasn't just a "modem"; it was a rugged industrial computer designed for this exact job.

This is the most basic edge router function, but it's the most critical. This edge router had to be more reliable than the pump itself.

• The Problem: These remote sites had spotty cellular coverage. A single carrier (like AT&T) might be strong at one site but weak at another.
• The Solution: Each cellular edge router was equipped with Dual SIMs (e.g., AT&T and Verizon). The gateway's "Smart Roaming" feature constantly monitors the connection. If the primary carrier's signal drops, the edge router automatically fails over to the backup carrier in seconds. This ensured the data connection was virtually 100% available.

This device isn't just a router; it's a "smart" edge router (an IoT Gateway). It had to "talk" to the pump.

• Modbus Polling: The edge router connects to the pump controller's RS485 port. Using its built-in software, it was configured to act as a Modbus Master, polling the controller every 30 seconds for critical data: Motor_Amps, Pump_Runtime_Hours, Flow_Rate, Pump_Status.
• Direct I/O: The edge router's Digital Input (DI) port was wired directly to the critical "High-Level Float Switch." This meant if the water reached a crisis level, the edge router would know instantly, even if the main pump controller had failed. This edge router function is critical.

This was the feature that delivered the single biggest ROI. The entire fleet of edge router devices was managed by RCMS , our cloud platform.

• The Scenario: At 3 AM, an alert fires. The remote pump monitoring edge router at Station 77 reports that the PLC is "unresponsive."
• The Old Way: Wake up an on-call engineer, pay them 4 hours of overtime, and send them on a 1-hour drive.
• The RCMS Way: The operator logs into RCMS from their home laptop. They see the edge router is online (the 4G connection is fine), but the PLC behind it is frozen. They navigate to the device's control panel and use a connected relay (controlled by the edge router's power control features) to remotely reboot the PLC's power supply.
• The Result: The PLC comes back online. The problem is solved in 5 minutes. The truck roll is eliminated. The engineer goes back to sleep. This remote management of the edge router is a TCO game-changer.

Deploying a true industrial edge router platform for their smart water management initiative yielded immediate, massive results.

• 90% Reduction in "Truck Rolls": Manual weekly inspections were completely eliminated. 9 out of 10 "failure" alerts were diagnosed or resolved remotely via RCMS.
• Zero Catastrophic Overflow Events: In the first year, the DI-connected high-level alarms on the edge router fleet caught 5 potential overflow events, allowing operators to dispatch crews before a single drop was spilled.
• Predictive Maintenance: By tracking Motor_Amps from the edge router, they could see when a pump was starting to clog (amps go up). They shifted from "fix it when it breaks" to "clean it before it breaks," saving a fortune on emergency motor replacements.
• TCO & ROI: The utility calculated that the entire edge router solution paid for itself in under 6 months from the savings in truck rolls and avoided fines alone.

In smart water management, the edge router is not an IT accessory. It is a core piece of critical infrastructure, just as important as the pump or the pipe.

It's the "nervous system" that connects your remote assets to your central brain. This case study proves that a professional industrial edge router solution, combining rugged hardware (with Dual-SIMs and Modbus) and a powerful remote management platform (RCMS), is the only way to build a reliable, secure, and profitable modern utility network. Your edge router is your first line of defense against downtime. This edge router is the standard.
